Jack for trucks, agricultural machinery & contractors' machines
Features:
- Low minimum height of only 5.51 in DK40Q/DK60Q - 5.91 in DK100Q/DK120Q
- Can be fitted with pneumatic tyres for easy manoeuvring option
- Wide and robust frame made of high-strength steel
- Fitted with quick-lift pedal for easy reach of lifting point
- Precise and safe control whilst lowering
- Manual dead man’s release for optimum safety when lowering
- Built-in safety overload valve
- Ergonomically designed handle ensuring positive and safe operation
Specs:
DK40Q
Capacity: 4.4 Tons
Min. height: 5.51 in
Max. height: 23.62 in
Frame length: 31.50 in
Handle length: 37.40 in
Frame height: 9.45 in
Width: 19.69 in
Weight: 209 lbs
DK60Q
Capacity: 6.6 Tons
Min. height: 5.51 in
Max. height: 23.62 in
Frame length: 31.50 in
Handle length: 47.24 in
Frame height: 9.45 in
Width: 19.69 in
Weight: 209 lbs
DK100Q
Capacity: 11 Tons
Min. height: 5,91 in
Max. height: 23.03
Frame length: 31.69 in
Handle length: 47.24 in
Frame height: 10.24 in
Width: 20.87 in
Weight: 260 lb
DK120Q
Capacity: 13 Tons
Min. height: 5,91 in
Max. height: 23.03
Frame length: 31.69 in
Handle length: 47.24 in
Frame height: 10.24 in
Width: 20.87 in
Weight: 260 lb
